Place of Origin: | Guangdong,China |
Brand Name: | Roeasy |
Model Number: | CH-151 |
Certification: | SGS |
Minimum Order Quantity: | 1000 pieces |
Price: | $0.15 |
Packaging Details: | 2pcs/bag,5 poly bag / inner box,100pcs/ctn |
Delivery Time: | 25 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 5000000 pieces/month |
CH-152B2 is made by cold-rolled steel,
Double plated surface treatment: brass and nickle
One way close
Three specifications: full overlay, half-overlay and inset .
Packing:2pcs/bag, 5 poly bag / inner box,100pcs/ctn, support customized.
Full overlay: the cabinet door can cover the side plate completely, and the cabinet door is outside the cabinet body.
Half overlay: the cabinet door covers half of the side plate,and there are doors on both sides of the cabinet.
Inset: the cabinet door does not cover the side plate, and the cabinet door is inside the cabinet body.
There are different sizes for the height of full overlay and half overlay: 3mm, 5mm, 7mm, 12mm
Type | Slide-on mini hinge |
Material | Cold-rolled steel |
Surface Treatment | Nickel plated |
Door Thickness | 14-18MM |
Opening Angle | 95 degree |
Diameter of Hinge Cup | 35MM |
Weight | 28g |
Close Way | One way close |
Installation | Slide-on |
Optional Accessories | Screws |
Double Plated: Brass+Nickle Plated
Fast delivery:3-7 days sample shipping, 25-35days production.
Self-own factory: Over 31 years manufacturer experience in furniture hardware
One-stop solution service of furniture hardware,support OEM/ODM Design.
Project Solution Capability:
Professional design team support total solution for projects: Free graphic design and Cross Categories Consolidation.
